Structure and Function
A: PL120000.055
B: PL120000.055
E: 06.93 / T. Weiß
G: 06.93 / T. Weiß
Chapter: 5.5
Page: 5
?
5.5.2 Pneumatic core pull (optional)
The pneumatic core pull consists of an electrical 4/2 pulse
valve including all service connections for a plastic pipe, NW
6.
This functional module is installed on the left connecting wall
of the ejector shaft.
The hook-up to the core pull cylinder supplied by the
manufacturer is not part of the delivery package.
Moreover, it must be borne in mind that the pneumatic
compressed air supplied for the purpose must be dried and
oiled, and that the pneumatic pressure must not exceed 6 bar
(87 psi). All connecting elements must be strong enough to
withstand this pressure!
