Battenfeld PLUS 250/50 - Structure and Function

Structure and Function
A: PL120100.051
B: PL120100.051
E: 03.93 / T. Weiß
G: 06.93 / T. Weiß
Chapter: 5.1
Page: 1
?
5.4 5.5 5.7
5.2 5.3
Bild: PL0008.TIF
Chapter 5: Structure and Function
5.1 Overview of build groups
5.2 Closing unit
5.3 Injection unit
5.4 Hydraulic unit
5.5 Electric unit
5.6 Pneumatic unit (optional)
5.7 Control
