Operation
A: PL120100.060
B: PL120100.060
E: 03.93 / T. Weiß
G: 06.93 / T. Weiß
Chapter: 6
Page: 1
Chapter 6: Operation
6.1 Startup
The machine is switched on by pressing the master switch on
the control box door. If possible, the master switch should
always be activated without load, i.e. first press master switch
before switching on the heating.
Press the red EMERGENCY STOP button located on the
side of the control box and release by rotating in direction of
arrow (to check EMERGENCY STOP circuit).
Open and close protective grating (to check protective grating
circuit).
Put position selector on control panel into “Manual operation”
mode.
Press the “STOP” button on the control panel for a moment to
acknowledge error messages (if any).
Press “START” button on the control panel and check direction
of rotation of pump (see direction of arrow on hydraulic drive).
If direction is not correct, change 2 phases of the supply line
in the mains line of the machine.
The standard machine equipment includes an oil preheating
system and thus can only be put into operation after the preset
preheating temperature has been attained (this takes appr.
15 min.).
If the mould was delivered with the following options, the
corresponding option must be connected, or the “dummy
plug” provided for this purpose must be plugged in. This
“dummy plug” supplies the signals necessary for correct
operation.
a) Core pull interface
b) Ejector protection interface
c) Test balance interface
d) Interface for final ejector position safety device
e) Robot interface
