Battenfeld PLUS 250/50 - Diagram; Closing Pressure; Diagram; Closing Velocity; A: Pl120100.030; Plus 250

Technical Data
A: PL120100.030
B: PL120000.030
E: 03.93 / T. Weiß
G: 06.93 / T. Weiß
Chapter: 3
Page: 8
3.8 Diagram / Closing pressure
Bild: PL-0018.WMF
470
423
376
329
282
235
188
141
94
47
10 20 30 40 50 60 70 80 10090
Plus 250
Plus 350
(18,50)
(16,65)
(14,80)
(12,95)
(11,10)
(9,25)
(7,40)
(5,55)
(3,70)
(1,85)
mm / sec
inch / sec
v [%]
Bild: PL-0018.WMF
350
315
280
245
210
175
140
105
70
35
10 20 30 40 50 60 70 80 10090
Plus 350
(38,5)
(34,7)
(30,9)
(27,0)
(23,2)
(19,3)
(15,4)
(11,6)
(7,7)
(3,9)
kN
(shtn)
Bild: PL-0018.WMF
250
225
200
175
150
125
100
75
50
25
10 20 30 40 50 60 70 80 10090
Plus 250
kN
(shtn)
(27,5)
(24,8)
(22,2)
(19,3)
(16,5)
(13,8)
(11,0)
(8,2)
(5,5)
(2,8)
p
[%]
p
[%]
3.9 Diagram / Closing velocity
