Technical Data
A: PL120100.030
B: PL120000.030
E: 03.93 / T. Weiß
G: 06.93 / T. Weiß
Chapter: 3
Page: 9
3.10 Diagram / Closing stroke
mm
(inch)
200
180
160
140
120
100
80
60
40
20
Bild: PL-0017.WMF
100908070605040302010
(7,87)
(7,09)
(6,30)
(5,51)
(4,72)
(3,94)
(3,15)
(2,36)
(1,57)
(0,79)
Plus 250
Plus 350
s [%]
3.11Fitting dimensions of machine
Please find data in the enclosed platen diagram at the end of
this chapter.
3.12 Dimensions of mould
A) Minimum mould diametre
The closing system with the two closing cylinders provides
an even transmission of the closing force to the mould and
thus ensures the precise distribution of forces. These
functions, however, can only by fulfilled if a minimum mould
diametre is observed, thus keeping the deflection of the
platens within acceptable limits.
