Technical Data
A: PL120100.030
B: PL120000.030
E: 03.93 / T. Weiß
G: 06.93 / T. Weiß
Chapter: 3
Page: 10
Since the measuring precision of the injection pieces, the
additional load for the mould and the mould functions (in case
of complicated designs, such as multiplate moulds, slide
moulds etc) are influenced by the degree of deflection of the
platens, the observance of these standard values ensures
that inacceptable overloading of the closing unit and mould
is excluded. For this reason, the following minimum mould
dimensions should be respected while generally maintaining
adequate closing pressure, in accordance with the required
closing force to keep mould wear and energy consumption
low.
PLUS 250 minimum mould diametre 160 mm (6,3 inch)
PLUS 350 minimum mould diametre 160 mm (6,3 inch)
Special attention should be paid to eccentricities (if any) of
the mould and the seal surface which might cause
deformations of both mould and closing unit, thus greatly
reducing the life of the guiding and sealing elements.
B) Maximum mould weight
The required measuring precision of the injection piece, the
mould stress and the mould functions (in case of complicated
designs, such as multiplate moulds, slide moulds etc) are
highly dependent on the plane parallel alignment of the
platens.
The plane parallel alignment stipulated by EUROMAP 9 is
observed if the following total mould weights are observed:
PLUS 250 max. mould weights 140 kg (315 lbs)
PLUS 350 max. mould weights 140 kg (315 lbs)
The weight of the closing plate half of the mould must not
exceed 2/3 of the specified total mould weight.
ATTENTION !
ATTENTION !
