A: PL120100.056
B: PL120100.056
E: 03.93 / T. Weiß
G: 06.93 / T. Weiß
Chapter: 5.6
Page: 2
?
Structure and Function
Bild: Pl-0022.TIF
1
2
4
5
11
7
9
6
10
8
3
5.6.2 Control box
The control box is easily accessible; it is located at the front
of the machine and contains the majority of the electrical
devices necessary for operation.
Front view of control box:
1) EMERGENCY STOP button
2) Manual control panel
3) Input panel
4) Auxiliary control panel
5) Pull-out error-indication lamp
6) Outlet filter
7) Inlet filter
8) Control box door
9) Door lock
10) Door handle
11) Master switch
