A: PL120100.056
B: PL120100.056
E: 03.93 / T. Weiß
G: 06.93 / T. Weiß
Chapter: 5.6
Page: 4
?
Structure and Function
Bild: Pl-0025.TIF
23
45
61
879
Back view of control box:
1) Cable outlets
2) Socket heater band - nozzle
3) Socket heater band - zone 1
4) Socket heater band - zone 2
5) Reserve
6) Cable thermocouple sensor - nozzle (optional)
7) Cable thermocouple - zone 1
8) Cable thermocouple - zone 2
9) Reserve
