Structure and Function
A: PL120101.054
B: PL120100.054
E: 03.93 / T. Weiß
G: 06.93 / T. Weiß
Chapter: 5.4
Page: 7
?
the required hydraulic valves and the consumer’s terminals
(2 x R1/4").
This function module is mounted on the left connecting wall
of the piece ejection shaft.
The delivery package does not include a connection to the
mould core pull cylinder.
Furthermore, it must be borne in mind that the available
hydraulic pressure is 210 bar (3045 psi). All connecting
elements must withstand this pressure!
