Add-on module SVP
Application handbook Servo pump function V1 for BM5000
Document No.: 5.17002.02 Baumüller Nürnberg GmbH
26
of 76
3.3
3.3 Add-on module SVP
The add-on module SVP provides an I/O-extension. The add-on module SVP has to be
mounted in production, it’s not pluggable or can be retrofitted.
Up to now there are three types of add-on module SVP.
Module with additional analog/digital inputs/outputs, BM53XX-XXXX-XX04
BM53XX-XXXX-XX05
BM53XX-XXXX-XX06
Types
The add-on module is required at servo pump systems with
m Ana
log set value interface or
m Pr
essure sensor with current interface or
m Hig
h precision applications
Evaluation: edges, programmable
Input current (p
er input): 2 mA digital input
Time delay input: max. 4 ms,
Level: Low (0 ... 5 V); High (1228 V)
Output current of each output: max. 500 mA
Electrical isolation: optocoupler
Short circuit proof: current limited, switch-off via temperature
Resolution 12 bit
Output voltage -10 V to +10 V
Output curr
ent max. 1 mA
Updating rate 125 µs
Short circuit proof limited, max. 10 s
Digital inputs/outputs
Analog outputs
Version Analog in 1 / 2 Analog in 3 / 4 Analog out 1 ... 4 Digital in 1 ... 4
Digital out 1 ... 4
SVP-001-001
BM53XX-XXXX-XX04
Analog voltage
inputs ±10 V
resolution 14 bit
Analog voltage inputs
±10 V
resolution 14 bit 4 analog
voltage outputs
±10V
resolution 12 bit
4 digital inputs
24 V /
4 digital outputs
24 V
SVP-001-002
BM53XX-XXXX-XX05
Analog voltage
inputs ±10 V
resolution 14 bit
Analog current inputs
(0) 4…20 mA
resolution 14 bit
SVP-001-003
BM53XX-XXXX-XX06
Analog current inputs
(0) 4…20 mA
resolution 14 bit
Analog current inputs
(0) 4…20 mA
resolution 14 bit
