Baumuller b maXX 5000 - 5 Error Messages

51
of 76
Application handbook Servo pump function V1 for BM5000
Document No.: 5.17002.02
5ERROR MESSAGES
The following table shows all Servo pump related errors with the Code, RC value, reaction
and description:
Code RC Reaction Description
1200 RC_INCOMPATUBLE_PLC_PRJ Stopping drive Firmware and PLC project 
versions does not match.
1201 RC_WIRE_BRAKE Stopping drive Sensor wire brake occurred.
1202 RC_PUMP_PROTECTION Stopping drive Missing oil flow.
1203 RC_THERM_OVERLOAD_PUMP Open bypass via P177.2 |
bit 8 = 1
Thermal overload exceeded.
