6.3 Parameter description
176.1 Mode 
DWORD 0x00000000 to 0xFFFFFFFF
Activation of the analog input and output channels:
Bit Meaning
0 1: Switch on channel analog input 1
0: Switch off channel analog input 1
1 1: Switch on channel analog input 2
0: Switch off channel analog input 2
2 1: Switch on channel analog input 3
0: Switch off channel analog input 3
3 1: Switch on channel analog input 4
0: Switch off channel analog input 4
4 … 7 Reserved
8 1: Switch on channel analog output 1
0: Switch off channel analog output 1
9 1: Switch on channel analog output 2
0: Switch off channel analog output 2
10 1: Switch on channel analog output 3
0: Switch off channel analog output 3
11 1: Switch on channel analog output 4
0: Switch off channel analog output 4
12 … 31 Reserved
