Baumuller b maXX 5000 Application Handbook

Installation
Application handbook Servo pump function V1 for BM5000
Document No.: 5.17002.02
29
of 76
3
3.3.2 Connection pressure sensor with voltage interface
Connection example for a pressure sensor with voltage output (3-wire version):
Figure 24: Typical connection pressure sensor with voltage interface
The 24 V supply of pressure sensor is directly supplied by the add-on module SVP.
Supply 24 V
Output 0..10 V
Pressure Transmitter
GND
Pressure sensor
