Baumuller b maXX 5000 Application Handbook

Parameter description
Application handbook Servo pump function V1 for BM5000
Document No.: 5.17002.02 Baumüller Nürnberg GmbH
56
of 76
6.3
176.2 Mode analog inputs 
DWORD 0x00000000 to 0xFFFFFFFF
Configuration of the analog inputs
176.6 Status digital inputs 
WORD 0x0000 to 0xFFFF
Status of the digital inputs
Bit Meaning
Bit 0 … 23: Oversampling
Oversampling factor: 0 … 8
3 … 0 Oversampling factor analog input 1
7 … 4 Oversampling factor analog input 2
11 … 8 Oversampling factor analog input 3
15 … 12 Oversampling factor analog input 4
16 … 23 Reserved
Only if the relevant analog input is a current input:
Bit 24 … 27: Current input range
0: 0 … 20 mA (
 no wire break detection)
1: 4 … 20 mA (
 wire break detection active)
24 Analog input 1
25 Analog input 2
26 Analog input 3
27 Analog input 4
28 … 31 Reserved
Bit Meaning
0 Status digital input 1:
0: disabled 1: active
1 Status digital input 2:
0: disabled 1: active
2 Status digital input 3:
0: disabled 1: active
3 Status digital input 4:
0: disabled 1: active
4 … 15 Reserved
