Baumuller b maXX 5000 Application Handbook

Parameters
Application handbook Servo pump function V1 for BM5000
Document No.: 5.17002.02
57
of 76
6
176.7 Status digital outputs 
WORD 0x0000 to 0xFFFF
Status of the digital outputs
The digital outputs of add-on module SVP are fixed linked:
Output 1: 24 V Drive enabled
Output 2: 24 V No error on the drive
Output 3: 24 V Motor temperature warning threshold 1 exceeded
176.8 Value analog input 1 
FLOAT -25 to +25
Volume set value in case of analog set values.
Scaling:
Voltage input: 1 V = 1,0
Current input: 1 mA = 1,0
176.9 Value analog input 2 
FLOAT -25 to +25
Pressure set value in case of analog set values.
Scaling:
Voltage input: 1 V = 1,0
Current input: 1 mA = 1,0
Bit Meaning
0 Status digital output 1:
0: disabled 1: active
1 Status digital output 2:
0: disabled 1: active
2 Status digital output 3:
0: disabled 1: active
3 Status digital output 4:
0: disabled 1: active
4 … 15 Reserved
