Baumuller b maXX 5000 Application Handbook

Guided Commissioning
Application handbook Servo pump function V1 for BM5000
Document No.: 5.17002.02
39
of 76
4
h Click on „Activate servo pump“. 
Check whether the PLC state is running (green) or not.
h If
there are any error's, please contact the Application-Department of Baumüller.
Figure 38: Guided commissioning: Activate the servo pump
h Click on „Continue“
h Set th
e pressure range for the pressure sensor and the flow rate of the pump.
Figure 39: Guided commissioning: Pressure range and flow rate
h Click on „Continue“
