Instruction Handbook b maXX (BM4-F-)ENC-XX (Encoder module)
Document No.: 5.01042.12
4DESIGN AND OPERATION
A b maXX BM4000 device consists of power unit and controller part
Figure 1: b maXX BM4000)
The BM4-F-ENC-XX is designed as plug-in module for standard controller and can be re-
placed or upgraded.
The ENC-XX is mounted stationary in the ES controller.
Power unit Controller part
standard controller
Design cover
(standard controller only)
BM4XXX-XXX-XX1XX
BM4XXX-XXX-XX2XX
BM4XXX-XXX-XX3XX
Standard controller
BM4XXX-XXX-XX4XX
BM4XXX-XXX-XX5XX
ES controller
Controller part
ES controller
