Baumuller b maXX BM4 Series Instruction

Installation
Instruction Handbook b maXX (BM4-F-)ENC-XX (Encoder module)
Document No.: 5.01042.12
65
of 102
7
7.4 Installation procedure
1 Switch off the b maXX 4400 device and assure it against unintentional switching on
during mounting.
2 Take off the cover from the controller unit (standard controller only)
n Standard controller:
The BM4-F-ENC-XX is located in slot A or B
n ES controller:
The ENC-XX is located in position A or B
3 Connect (BM4-F-)ENC-XX and motor (connection cables see ZConstruction guid-
ance connection cables– from page 59 or ready-for-use ZConnection cable– from
page 90 (outgoing cable downwards).
4 Attach the cover to the device again (standard controller only)
5 Install the cables according to the instructions into the switching cabinet, see ZRe-
quirements on the electrical connection– on page 46.
DANGER!
Risk of fatal injury from electrical current!
There is an immediate risk of fatal injury if live electrical parts are contacted.
Therefore:
m Switch off the current when any kind of work is being performed on the electrical
system and ensure safety before switching on again.
m Pay attention to the relevant safety instructions when handling electrical equip-
ment carrying high voltages.
m Do not touch electrically live parts before taking into account the discharge time of
the capacitors.
