Instruction Handbook b maXX (BM4-F-)ENC-XX (Encoder module)
Document No.: 5.01042.12
8COMMISSIONING/OPERATION
This test-commissioning assures, that the (BM4-F-)ENC-XX has been correctly recog-
nized. Further information relating to commissioning and parameter settings of the encod-
er module can be found in parameter manual b maXX 4000 5.03039.
Assure, that before commissioning the following preconditions are fulfilled:
1 The BM4-F-ENC-XX is correctly mounted (standard controller only).
2 The encoder is correctly mounted at the motor.
The encoder must be suitable for the encoder module, must be approved by Baumüller
Nürnberg GmbH and must be correctly cabled.
3 The switching cabinet is properly closed and all safety devices are put into operation.
4 The b maXX 4000 is ready-for-use.
8.1 Safety notes
Basics
WARNING!
Risk of injury due to improper operation!
Improper operation can lead to severe personal injury or material damage.
Therefore:
m Perform all operational steps according to the details of these instruction hand-
book.
m Before beginning any work, ensure that all coverings and protective devices are
installed and are functioning properly.
m The control cabinet in which the device is installed should be protected against
contact with electrically live parts.
Keep all doors of the control cabinet closed during operation.
