11.2 Connection cable
m Encoder cable 12-wire
Encoder cable for resolver, sine cosine encoder with Hiperface
®
interface and square
ware incremental encoder
ready-for-use - trailing cable available, length see below, further lengths on request
Bold: preferred length
Length
not trailing cable
Part no.
trailing cable
Part no.
SpeedTec
trailing cable
Part no.
1 m 243601 - 448941
2 m 211338 - 448943
3 m 219333 246658 448944
4 m 231166 243379 448945
5 m 209879 239540 448948
6 m 220197 242954 448946
7 m 216455 - 448947
8 m 220429 239541 448949
10 m 210052 239542 448956
15 m 215716 239543 448961
20 m 218568 239544 448967
25 m 218569 239545 448970
30 m 217094 239546 448971
35 m 216444 239547 448973
40 m 217095 240520 448976
45 m 217567 240521 448978
50 m 217568 240522 448979
55 m 217569 244033 448981
60 m 217570 245484 448982
70 m 232088 - -
