Baumuller b maXX BM4 Series Instruction

Accessories and Spare Parts
Instruction Handbook b maXX (BM4-F-)ENC-XX (Encoder module)
Document No.: 5.01042.12
91
of 102
11
m EnDat
®
2.1 encoder cable
ready-for-use - trailing cable available, length see below, further lengths on request
Bold: preferred length
Length
not trailing cable
Part no.
trailing cable
Part no.
SpeedTec
trailing cable
Part no.
2 m 383152 393889 448816
3 m 383923 369864 448817
5 m 393885 394014 448818
7 m 389445 389807 448819
8 m 380138 393890 448820
9 m 389446 389808 448821
10 m 393886 393891 448822
15 m 388505 393892 448823
17 m - 371494 448824
20 m 388418 393893 448825
25 m 393887 393894 448826
30 m 393888 380358 448827
35 m 387958 391216 448828
40 m 382006 382005 448830
50 m 388419 378022 -
70 m 384473 - -
90 m 387391 - -
NOTE
No evaluation of the motor temperature sensor is possible with this encoder cable!
