Baumuller b maXX BM4 Series Instruction

Connection cable
Instruction Handbook b maXX (BM4-F-)ENC-XX (Encoder module)
Document No.: 5.01042.12 Baumüller Nürnberg GmbH
92
of 102
11.2
m EnDat
®
2.2 encoder cable
without incremental encoder signals
Original encoder cable of Fa. Heidenhain), lengths on request.
Cable with M12 connector 8-pin completely assembled with female connector and male
Sub-D connector.
Order No. Fa. Heidenhain
524599-xx (xx: length)
