Instruction Handbook b maXX (BM4-F-)ENC-XX (Encoder module)
Document No.: 5.01042.12
6MOUNTING
In this chapter we describe the mechanical mounting of the plug-in module
BM4-F-ENC-XX for BM4400, BM4600, BM4700 with standard controller.
6.1 Preparation of mounting
h Check the marking ENC-XX, wether the right plug-in module is available.
Figure 5: BM4-F-ENC-XX for standard controller
h Determine the suitable slot, slots A and B are possible (also refer to ZSlots BM4-F-
ENC-XX for standard controller– on page 30).
NOTE!
The encoder modules are mounted stationary in the BM4400, BM4600, BM4700
with ES controller and cannot be changed, therefore no mounting is necessary!
