4.2.2 Type plate BM4-F-ENC-XX for standard controller
The type plate can be found on the connector on the back side of the BM4-F-ENC-XX.
The type code and the serial No. are printed on the type plate.
Figure 3: Type plate BM4-F-ENC-XX for standard controller
NOTE!
EtherCAT option modules must not be plugged in slot J of a 3-rowed controller unit,
because the module can be damaged.
In case another BM4X-X-XXX plug-in module is plugged in an unsuitable slot, it will
not operate. We have made sure, that neither the module nor the device are dam
-
aged.
Type plate
e.g.
back side
BM4-F-ENC-05
S12345678
