Requirements on the electrical connection
Instruction Handbook b maXX (BM4-F-)ENC-XX (Encoder module)
Document No.: 5.01042.12 Baumüller Nürnberg GmbH
46
of 102
7.2
7.2 Requirements on the electrical connection
Use the recommended cables in order to comply with the standard EN 60 204-1 (Electri-
cal Equipment of Machines). Short-circuits, external voltage etc. may occur, if the con-
nectors are not fixed.
NOTICE!
The danger is: Electricity.
In case you do not ensure the requirements to the electrical connection of the
ENC-XX/BM4-F-ENC-XX, it can be damaged/destroyed.
1 The ENC-XX/BM4-F-ENC-XX supplies the connected encoders with voltage and
current. Exceptions are only possible, if this is mentioned in the specific module
characterization.
2 Therefore it is forbidden to connect encoders to an external voltage supply, in par-
ticular when this external voltage supply is not the same supplying the b maXX
4000
device. The product liability expires, if the encoders are not supplied with
voltage and current by a ENC-XX/BM4-F-ENC-XX module; this is a forbidden and
not designed use of the encoder systems.
3 Should alternative supply concepts be considered, please contact Baumüller in
advance.
NOTE!
Pay attention to EMC compatible cabling, see instruction handbook b maXX
BM4400, BM4400 ES, BM4600, BM4600 ES, BM4700, BM4700 ES (5.12008), chap
-
ter Installation requirements with regard to EMC.
