ENC-XX in ES controller
Instruction Handbook b maXX (BM4-F-)ENC-XX (Encoder module)
Document No.: 5.01042.12 Baumüller Nürnberg GmbH
36
of 102
4.3
4.3.2 Type plate ENC-XX in ES controller
The type code of the ENC-XX is included in the type plate of the basic unit.
4.3.3 Type code ENC-XX in ES controller
The type code has the form:
BM4XXX - XXX - XXXXX[Ryy] - [XXXXXXXX] - [XXX] - XX.
Directly behind the type code is the version code
(- XXXX - X - XXX - XXX).
Only the shown section is valid for the ENC-XX in ES controller.
NOTE!
Only 2 analog outputs can be parametrized or linked even more than one AIO module
is available.
BM4XXX - XXX - XXXXX[Ryy] - [XXXXXX] - [XXX] - XX Device generation
BM4XXX - XXX - XXXXX[Ryy] - [XXXXXXXX] - [XXX] - XX
ES controller function module, position A
BM4XXX - XXX - XXXXX[Ryy] - [XXXXXXXX] - [XXX] - XX
ES controller function module, position B
0
A
B
C
D
E
F
G
H
I
J
K
L
W
no function module
Resolver see
Sine cosine Hiperface
®
see
Square wave incremental encoder see
Sine cosine zero-point sensing see
Sine cosine with EnDat
®
2.1 see
Absolute value encoder with EnDat
®
2.2 see
Sine cosine with SSI, 5 V external see
Sine cosine with zero-point sensing see
Sine cosine Hiperface
®
without termination in
RS485 communication see
Square wave incremental encoder without
cable break recognition see
Sine cosine with EnDat
®
2.1 reference track see
Sine cosine with SSI, 5 V internal see
SSI encoder with 24 V see
ENC-21
ENC-02
ENC-03
ENC-04
ENC-05
ENC-06
ENC-07
ENC-08
ENC-12
ENC-13
ENC-15
ENC-17
ENC-27
