Baumuller b maXX BM4 Series Instruction

Design and Operation
Instruction Handbook b maXX (BM4-F-)ENC-XX (Encoder module)
Document No.: 5.01042.12
33
of 102
4
4.2.3 Type code BM4-F-ENC-XX for standard controller
Type code:
4.2.4 Danger areas BM4-F-ENC-XX for standard controller
The BM4-O-ENC-XX can be operated in combination with BM4000, only. Please note all
safety notes of the basic unit b
maXX BM4000.
NOTE!
This type code is valid for the encoder modules BM4-F-ENC-XX of series b maXX
BM4000 exclusively. For other plug-in modules are different type codes available.
BM4 -F - ENC - XX Device family, in which the plug-in module can be built in
BM4 -F - ENC - XX Type of plug-in module (function module)
BM4 -F - ENC - XX Name of plug-in module
BM4 -F - ENC - XX Version plug-in module
01: Resolver module
11: Resolver module with reduces level
21: Resolver module
02: Sine cosine encoder module with hiperface
®
interface
12: Sine cosine encoder module with hiperface
®
interface without
termination in communication
03: 5V square wave incremental encoder module
05: Sine cosine encoder module with EnDat
®
2.1-interface
06: Encoder module with EnDat
®
2.2-interface
04: 5V sine cosine incremental encoder module
with zero point sensing
07: Sine cosine encoder module with SSI interface
17: Sine cosine encoder module with SSI interface and 5 V power supply
27: Sine cosine encoder module with SSI interface and 24 V power supply
08: 5V sine cosine encoder module with commutation
