4.3 ENC-XX in ES controller
The encoder module ENC-XX is mounted stationary in the ES controller.
Figure 4: ENC-XX in the ES controller
The controller is ordered with the desired function/option modules, these are mounted
stationary (exception slot H) and cannot be changed. Only the option module in slot H can
be changed/added.
e.g.
ENC-01
position A
e.g.
ENC-05
position B
ENC-01
position A
ENC-05
position B
