baxter AK98 - Back Panel

CONFIGURATION - BACK PANEL
1. Transportation handle
2. Air filters
3. Halt button
4. Battery charge indicator
5. Battery connect indicator
6. Over temperature protection
indicator
7. Inlet water tube
8. Outlet tube (drain)
9. Citric acid inlet tube
10. Ethernet port
11. USB port
12. External communication port
13. Mains connection
14. Fuses
15. Main switch
16. Blood leak detector
17. Priming bucket
18. Ultrafilter
19. Leakage detector tray
20. Potential equalisation
connection
4
17
15
1
2
3
4
5
6
7
8
9
14
13
12
11
10
16
18
19
20
