Installation manual

HB-37420-810-01-25F-EN SMX100 Installation manual.docx Page 125 of 260

Version: 25F

5.3.1 Arrangement examples

5.3.1.1 SMX100-1 + SMX122 + SMX5x

There is no TB2 between the SMX122 module and the communication module SMX5x because

the power supply for the SMX5x is fed in through the backplane bus system.

5.3.1.2 SMX100-2 + SMX121-2 + SMX5x

There is no TB2 between the SMX121-2 module and the communication module SMX5x

because the power supply for the SMX5x is fed in through the backplane bus system.

SMX122

SMX100-1

SMX100-2

SMX121-2

SMX5x
