3.2.4.4 Encoder specifications
TTL
Physical Layer
RS-422 compatible
Measuring signal A/B
Track with 90 degree phase difference
Max. frequency of input cycles (X31,
X32 / X33, X34)
250 kHz / 500 kHz
Type of connection
D-SUB 9pol
Sin / Cos
Physical Layer
RS-422 compatible
Measuring signal A/B
Track with 90 degree phase difference
Standard mode
Max. frequency of input cycles
(X31, X32 / X33, X34)
250 kHz / 500 kHz
High Resolution Mode
Max. frequency of input cycles
(X33, X34)
15 kHz
Type of connection
D-SUB 9pol
SSI-Absolut
Data interface
Serial Synchronous Interface (SSI) (SSI) with variable
data length of 12 – 28 Bit
Data format
Binary, grey code
Physical Layer
RS-422 compatible
SSI-Master operation:
Clock rate
150 kHz
SSI-Listener- operation (slave mode)
Clock rate (X31, X32 / X33, X34)
250 kHz / 350 kHz
Min. clock pause time
150 µsec
Max. clock pause time
1 msec
Type of connection
D-SUB 9pole
Resolver
Measuring signal
Sin/Cos – track with 90° phase difference
Signal frequency
max. 600 Hz (900Hz Deep pass)
Input voltage
max. 8 Vss (an 16 kΩ)
Resolution:
9 Bit / pole
Supported pole number
2 - 16
Reference frequency (Listener)
4 kHz – 16 kHz
Reference frequency (Master)
8 kHz
Reference amplitude
8 Vss – 28 Vss
Reference signal form
Sinusoidal, triangle
Transformation ratio
2:1; 3:1; 4:1
Phase fault
max. 8°
Type of connection (X33, X34)
D-SUB 9pole
HTL
Signal level
24V / 0V
Physical Layer
PUSH / PULL
Type of connection (X27, X28, X29,
X30)
Plug-in terminals with spring or screw connection
Proxi
Signal level
24V / 0V
Max. counting pulse frequency
(switching logic debounced)
10 kHz
Type of connection (X23)
Plug-in terminals with spring or screw connection
Proxi – Extended monitoring
Signal level
24V / 0V
Max. counting pulse frequency
(switching logic debounced)
10 kHz
Physical Layer
PUSH / PULL
Measuring signal A/B
Track with 90 degree phase difference
Type of connection (X23)
Plug-in terminals with spring or screw connection
