7 Start-up
7.1 Procedure
Start-up must only be performed by qualified personnel!
Strictly follow the safety regulations when commissioning!
7.2 Making sequences
The following phases are passed through and displayed by the front side seven segment
display after each new start and fault-free running of the module:
7 segment display
Mode
Description
„1“
STARTUP
Synchronization between both processor
systems and checking of
configuration/firmware data
„2“
SENDCONFIG
Distribution of configuration/firmware data
and renewed checking of these data.
Subsequent area checking of
configuration data.
„3“
STARTUP BUS
If available, initialization of a bus system
„4“
RUN
Normal system operation. All outputs are
switched according to the current logic
status.
„5“
STOP
In stop mode parameter and program
data can be loaded externally.
„A“
ALARM
The alarm can be reset via the digital
input or the front side reset button.
„E“
ECS-Alarm
The ECS alarm can be reset via the
digital inputs or the front side reset button.
„F“
Fault
Fault can only be reset via ON/OFF of the
module.
„.“
FBus Status
Slave F-Bus (PROFIsafe/FSoE):
Off:
F-Bus does not use
Slow
Flashing:
F-Bus configured, no
connection to the master
Fast
flashing:
Connection to the master,
F-Bus activation pending
On:
F-Bus connected
