3.2.4.3 Optional universal communication interface
Specification
Device design
/D
Decentralised SDDC and SMMC interface (2x RJ
45)
Communication interface for decentralized slave and
master modules
/xN
Field bus interface (2x RJ 45)
Standard and safe fieldbus
/xB
Field bus interface (Sub-D)
Standard and safe fieldbus
/xxM
MemoryCard (Mini SD)
Storage medium for safety program
Properties of the universal communication interface:
• Optional specification of the SMX series communication interface
• Subsequent expansion capability of standard to safe field bus via additional Mini SD
card on the back side of the module is possible. (/xNx and /xBx)
• Different specifications can be combined. See „combination options“.
• You can take detailed information from the installation manuals of the respective field
bus modules.
3.2.4.3.1 Combination options
Specifications
/D
/DxM
/DNM
/xNM
/xxM
/DBM
/xBM
Module type
SMX100-1/2
x
x
x
x
x
x
x
SMX100-2/2
x
x
x
x
x
x
x
SMX100-4/2
x
x
x
x
x
x
x
SMX111/2
x
SMX111-2/2
x
SMX112/2
x
SMX112A/2
x
SMX112-2/2
x
SMX112-2A/2
x
SMX131/2
SMX131R/2
SMX131R-4/2
SMX132-0/2
x
SMX132-1/2
x
SMX132-0R/2
x
SMX132-1R/2
x
