Page #134 background imageLoading...
Page #134 background image
Installation manual
HB-37420-810-01-25F-EN SMX100 Installation manual.docx Page 134 of 260
Version: 25F
Terminal assignment
Unit
Terminal
Pin
Pin
SMXGen2 (/2)
Description
Note
REL
X41
1 - U24_EXT
1 - A1.1
Voltage supply device +24 VDC
2 - U24_EXT
2 - A1.2
Voltage supply device +24 VDC Outputs
3 - GND_EXT
3 - A2.1
Voltage supply device 0 VDC
4 - GND_EXT
4 - A2.2
X42
1 - DI13
1 - I13
Safe digital inputs
2 - DI14
2 - I14
3 - P1
3 - T1
Clock outputs
4 - P2
4 - T2
X43
1 - DO0_P
1 - Q1
Output of the pp-switching DO 0_P (Q1_PP) / pp-
switching (Q1)
from SMXGen2
(/2) alternatively
via SafePLC2
parameterizable
2 - DO0_M
2 - Q2
Output of the pn-switching DO 0_M (Q2_PN) / pp-
switching (Q2)
3 - DO1_P
3 - Q3
Output of the pp-switching DO 1_P (Q3_PN) / pp-
switching (Q3)
4 - DO1_M
4 - Q4
Output of the pn-switching DO 1_M (Q4_PN) / pp-
switching (Q4)
X44
1 - K1.1
1 - Q5.1
Safe relay output
2 - K1.2
2 - Q5.2
3 - K2.1
3 - Q6.1
Safe relay output
4 - K2.2
4 - Q6.2
Terminal assignment
Unit
Terminal
Pin
Pin
SMXGen2 (/2)
Description
Note
IO
X45
1 - U24_EXT
1 - A1.3
Voltage supply device +24 VDC Outputs
2 - U24_EXT
2 - A1.4
3 - GND_EXT
3 - A2.3
Voltage supply device 0 VDC
4 - GND_EXT
4 - A2.4
X46
1 - IO1
1 - IQ01
Safe digital inputs, outputs pp-switching
2 - IO2
2 - IQ02
3 - DO0.3
3 - Y3
Auxiliary outputs
4 - DO0.4
4 - Y4
X47
1 - IO3
1 - IQ03
Safe digital inputs, outputs pp-switching
2 - IO4
2 - IQ04
3 - IO5
3 - IQ05
4 - IO6
4 - IQ06
X48
1 - IO7
1 - IQ07
2 - IO8
2 - IQ08
3 - IO9
3 - IQ09
4 - IO10
4 - IQ10
