BBH SMX Series User Manual

Installation manual
HB-37420-810-01-25F-EN SMX100 Installation manual.docx Page 160 of 260
Version: 25F
Terminal assignment
Unit
Terminal
Pin
Pin
SMXGen2 (/2)
Description
Note
CPU-
ENC
X13
1 – U_ENC_1
1 – UE1+
Voltage supply encoder +24V DC X31
2 – GND_ENC_1
2 – UE1-
Voltage supply encoder 0V DC X31
3 – DO 0.1
3 – Y1
Auxiliary outputs
4 – DO 0.2
4 – Y2
X14
1 - DI1
1 - I01
Safe digital inputs
2 - DI2
2 - I02
3 - DI3
3 - I03
4 - DI4
4 - I04
X23
1 - DI5
1 - I05
2 - DI6
2 - I06
3 - DI7
3 - I07
4 - DI8
4 - I08
X24
1 - DI9
1 - I09
2 - DI10
2 - I10
3 - DI11
3 - I11
4 - DI12
4 - I12
Terminal assignment
Unit
Terminal
Pin
Pin
SMXGen2 (/2)
Description
Note
ENC
X15
1 – U_ENC_2
1 – UE2+
Voltage supply encoder +24V DC X32
2 – GND_ENC_2
2 – UE2-
Voltage supply encoder 0V DC X32
3 – NC
3 – NC
No function
4 – NC
4 - NC
X16
1 – NC
1 – NC
No function
2 – NC
2 – NC
3 – NC
3 - NC
4 – NC
4 – NC
X25
1 – NC
1 – NC
No function
2 – NC
2 – NC
3 – NC
3 - NC
4 – NC
4 – NC
X26
1 – NC
1 – NC
No function
2 – NC
2 – NC
3 – NC
3 - NC
4 – NC
4 – NC
