Installation manual
HB-37420-810-01-25F-EN SMX100 Installation manual.docx Page 17 of 260
Version: 25F
Release version of the aforementioned device types
The distinguishing of the device types takes place through the SMXGen2 characterization
e.g.: SMX100-1/2)
The following characteristics distinguish the two versions:
- Switchable outputs on the base devices; See technical data.
- Higher nominal loads of the outputs on the base devices. See technical data.
- Higher nominal loads of the outputs on the I/O expansion modules See technical data.
- Optional expansion possibility via „Universal communication module“; See “Optional
universal communication interface“
The following device types are available as SMXGen2 (/2):
Base devices
Expansion modules
SMX100-1/2(/x
(1)
)
SMX131/2
SMX100-2/2(/x
(1)
)
SMX131R/2
SMX100-4/2(/x
(1)
)
SMX131R-4/2
SMX132-0/2/D
SMX132-0R/2/D
SMX132-1/2/D
SMX132-1R/2/D
SMX111/2/D
SMX111-2/2/D
SMX112/2/D
SMX112A/2/D
SMX112-2/2/D
SMX112-2A/2/D
Options:
/5x - Standard field bus
/4x - Standard field bus and Safety-Protokoll
/x - Universal communication interface
/D - Decentral expansion module
A - Safe analogue inputs
R - Relay
(1)
Specification see: „Optional universal communication interface“
