BBH SMX Series - Page 172

Installation manual
HB-37420-810-01-25F-EN SMX100 Installation manual.docx Page 172 of 260
Version: 25F
Terminal assignment
Unit
Terminal
Pin
Pin
SMXGen2 (/2)
Description
Note
EXT-
REL
X09
1 – K5/11
1 – 1.11
Read back contact Relais 5
2 – K5/12
2 – 1.12
3 – K6/11
3 – 2.11
Read back contact Relais 6
4 – K6/12
4 – 2.12
X10
1 – K7/11
1 – 3.11
Read back contact Relais 7
2 – K7/12
2 – 3.12
3 – K8/11
3 – 4.11
Read back contact Relais 8
4 – K8/12
4 – 4.12
X19
1 – K5.1
1 – Q1.1
Safe relay output 5
2 – K5.2
2 – Q1.2
3 – K6.1
3 – Q2.1
Safe relay output 6
4 – K6.2
4 – Q2.2
X20
1 – K7.1
1 – Q3.1
Safe relay output 7
2 – K7.2
2 – Q3.2
3 – K8.1
3 – Q4.1
Safe relay output 8
4 – K8.2
4 – Q4.2
Terminal assignment
Unit
Terminal
Pin
Pin
SMXGen2 (/2)
Description
Note
IO
X11
1 - U24_EXT
1 - A1.3
Voltage supply device +24 VDC Outputs
2 - U24_EXT
2 - A1.4
3 - GND_EXT
3 - A2.3
Voltage supply device 0 VDC
4 - GND_EXT
4 - A2.4
X12
1 – IO01
1 - IQ01
Safe digital inputs, outputs pp-switching
2 – IO02
2 - IQ02
3 - DO0.3
3 - Y3
Auxiliary outputs
4 - DO0.4
4 - Y4
X21
1 – NC
1 – NC
No function
2 – NC
2 – NC
3 – NC
3 – NC
4 – NC
4 - NC
X22
1 – NC
1 – NC
2 – NC
2 – NC
3 – NC
3 – NC
4 – NC
4 - NC
