Appendix A: Technical Overview 109
Figure A-2 Hydrodynamic focusing of the sample core through the flow cell
When using BD FACSCanto clinical software, the cytometer automatically
regulates the sample pressure according to the currently selected panel.
Optics System
As stained cells or other particles pass through the focused laser beam, they
scatter the laser light and fluoresce. Because the laser beam is focused and
particles move rapidly through the flow cell, the scatter or fluorescence emission
has a very brief duration—only a few microseconds. This brief flash of light is
collected, filtered, and then converted into an electrical signal by the detectors.
high sample
pressure
(120 µL/min)
low sample
pressure
(10 µL/min)
red beam
sheath fluid
blue beam
sample
sheath fluid
sheath fluid
sample
sheath fluid
