Becker AR6201 - Installation Setup; Service Mode; Variants Survey

AR6201-(X0X)
Page 1-4 DV 14300.03/.04 Issue 5 5/2013
software versions of the control head and chassis module. The continuous
built in test (CBIT) verifies the correct function of the unit
permanently during normal operation. If a problem is detected an error
message will be displayed.
Installation Setup
Configuration of the installation parameters like mike sensitivity, mike
type selection, speaker ON/OFF and further parameters is possible via
the Installation Setup.
Service Mode
The Service Mode is a special configuration mode of the AR6201 via a
RS422 interface with a proprietary serial data communication protocol.
1.5 Variants Survey
Part Number
Article
Number
Panel
Color
Display
Color
25 kHz
Mode
8.33+25 kHz
Mixed Mode
AR6201-(000)
0610.321-910 black green Yes Yes
AR6201-(002)
0614.203-910 black blue - white
Yes Yes
AR6201-(100)
0621.218-910 black green Yes
Not
available
AR6201-(102)
0621.226-910 black blue - white
Yes
Not
available
