Becker AR6201 - 2.5 Installation and Configuration

AR6201-(X0X)
DV 14300.03/.04 Issue 5 5/2013 Page 2-31
2.9.2 Twin Seater Motor Glider
Typical Installation Wiring
Figure 2-7
Sub-Menu
Function: / Selection
“SPKR VOLUME SOURCE”: ................ BOTH
“CONFIGURATION” “SWAP MIKE IC”: Disabled
“IN/OUT CFG 1”: “MICROPHONE 1”: STD_
“MICROPHONE 2”:
NONE
“BOTH MIKES”: ...
Enabled
“HEADPHONE 1”: .
Enabled
“SPEAKER”: ..... Disabled
“IN/OUT CFG 2”: “MICROPHONE 1”: NONE
“MICROPHONE 2”:
DYN_MIKE
“BOTH MIKES”: ..
Enabled
“HEADPHONE 1”: .
Enabled
“SPEAKER”: .....
Enabled
Remarks The external switch (connected to pin J1-
24 /MIKE_SW) has the following functions:
Open: Standard Microphone is selected.
Speaker is disabled.
Intercom via VOX is possible.
Closed: Dynamic Microphone is selected.
Speaker is enabled.
No Intercom via VOX is possible.
Permanent speaker sign
is
visible on LCD screen.
