Becker AR6201 - Retrofitting an AR4201 with an AR6201-(X0 X); Pin Compatibility

AR6201-(X0X)
Page 2-34 DV 14300.03/.04 Issue 5 5/2013
2.10 Retrofitting an AR4201 with an AR6201-(X0X)
In most cases, a retrofit of the AR4201 with an AR6201-(X0X) does not
cause any problem.
However, in some cases differences may occur because not all pins are
fully compatible.
!!! To connect the AR6201-(X0X) to an AR4201 wiring does not cause any
defect, neither to the AR6201-(X0X) nor to the aircraft installation.
2.10.1 Pin Compatibility
Pin
No.
AR4201
Pin Name
AR4201
Function
AR6201-
(X0X)
Pin Name
AR6201-(X0X)
Function
Fully
compa
tible
P1-1 AF-ASYM
Speaker
output,
unbalanced
SPK_HI Speaker output,
unbalanced
Yes
P1-2 AF-HI
Headphone
output,
balanced
HDPH_A
Headphone
output, balanced
Yes
P1-3 AF-LO
Headphone
output,
balanced
HDPH_B
Headphone
output, balanced
Yes
P1-4 AFAUX
Auxiliary
audio input,
unbalanced
AF_AUX_IN_H
I
Auxiliary audio
input,
unbalanced
Yes
P1-5 MIKE DYN
Dynamic
microphone
input, high
side,
(unbalanced)
MIKE_DYN_HI
Dynamic
microphone
input,
(balanced)
Yes
P1-6 MIKE GROUND
Ground for
dynamic
microphone,
MIKE_DYN_LO
Dynamic
microphone
input,
(balanced)
No
P1-7 IC
Intercom
input
/IC Intercom input Yes
P1-8 TEMS1
Input for
temperature
sensor
MIKE_STD_LO
Ground
No
P1-9 RXD RS232 RXD NC Not connected
No
P1-10
-ILLUMINATION
Illumination,
low side
ILL_LO Illumination,
low side
Yes
P1-11
+13.75V
Positive
power supply
P_SUPP Positive power
supply
Yes
