AR6201-(X0X)
DV 14300.03/.04 Issue 5 5/2013 Page 2-35
Pin
No.
AR4201
Pin Name
AR4201
Function
AR6201-
(X0X)
Pin Name
AR6201-(X0X)
Function
Fully
compa
tible
P1-12
+13.75V
Positive
power supply
P_SUPP Positive power
supply
Yes
P1-13
GROUND
Power supply
return /
Ground
P_SUPP_GND Power supply
return / Ground
Yes
P1-14
AF GND
MIKE STD GND
Ground SPK_LO Ground Yes
P1-15
AFCU
Normally not
used in
airborne
installation
LINE_OUT
Normally not
used in airborne
installation
No
P1-16
AGC/AFWB
Normally not
used in
airborne
installation
AGC_OUT
Normally not
used in
airborne
installation
No
P1-17
PTT Push To Talk /PTT Push To Talk Yes
P1-18
MIKE STD.
Standard
microphone
input, high
side,
unbalanced
MIKE_STD_HI
Standard
microphone
input, high
side, unbalanced
Yes
P1-19
CPIN
coding pin
(removed pin)
CPIN coding pin
(removed pin)
Yes
P1-20
TEMS2
Ground for
Temperature
sensor
NC Not connected
No
P1-21
GNDDATA Ground AF_AUX_IN_L
O
Ground Yes
P1-22
TXD RS232 TXD NC Not connected
No
P1-23
+ILLUMINATION
Illumination,
high side
ILL_HI Illumination,
high side
Yes
P1-24
+13.75V
SWITCHED
Power on
monitor
Switched
positive
power supply.
/PWR_EVAL Power on
monitor,
open collector
output, GND if
“ON”.
No
P1-25
GROUND
Power supply
return /
Ground
P_SUPP_GND Power supply
return / Ground
Yes
