AR6201-(X0X)
Page 2-8 DV 14300.03/.04 Issue 5 5/2013
The transceiver provides with pin 7 connected to ground intercom
operation. This input has an internal pull up and is LO active at
max.1 mA. For installations where automatic intercom operation is
activated via VOX connection of this pin 7 is not necessary.
This discrete input activates intercom:
• when VOX does not work satisfactorily because of too high ambient
noise in the cockpit,
• or speaker is “enabled” in current audio in/out configuration
(Installation Setup).
/PWR_EVAL
Pin No. AR6201 Pin Name Direction Function
P1-24 /PWR_EVAL - Power on monitor output:
AR6201 “OFF” - open circuit
AR6201 on - closed circuit to GND
(max. 100 mA)
Refer Figure 2-5 for further guidance.
Note: In order to avoid damage of this output a protection diode in
parallel to the external relay shall connected.
/MIKE_SW (external Mike Switch)
Pin No. AR6201 Pin Name Direction Function
J1-24 /MIKE_SW IN Toggles between:
IN/OUT CFG 1 - open circuit
IN/OUT CFG 2 - closed circuit to GND
(configurable in Installation Setup)
The external Mike switch provides selection between the two available
audio in/out configurations.
