Becker AR6201 - Typical Settings in the INSTALLATION SETUP; Single Seater Glider

AR6201-(X0X)
Page 2-30 DV 14300.03/.04 Issue 5 5/2013
2.9 Typical Settings in the INSTALLATION SETUP
2.9.1 Single Seater Glider
Typical Installation Wiring
Figure 2-5, Figure 2-6
Sub-Menu
Function: / Selection
“SPKR VOLUME SOURCE”: ................ PRIMARY CH
“IN/OUT CFG1”: “MICROPHONE 1”: NONE
“MICROPHONE 2”:
DYN_MIKE
“BOTH MIKES”: ..
Enabled
“HEADPHONE 1”: .
Enabled
“SPEAKER”: .....
Enabled
“IN/OUT FG2”: N/A
Remarks
Permanent speaker sign
is visible on
LCD screen.
VOX operation suppressed.
