AR6201-(X0X)
DV 14300.03/.04 Issue 5 5/2013 Page 1-1
Section 1. GENERAL DESCRIPTION
1.1 Introduction
This manual describes the VHF transceiver AR6201-(X0X). The manuals DV
14300.03
I&O (“Installation and Operation”) and DV 14300.04 M&R
(“M
aintenance and Repair”) contain the following sections.
Section
DV 14300.03
I&O
DV 14300.04
M&R
1 General
X X
2 Installation
X X
3 Operation
X X
4 Theory of Operation
N/A X
5 Maintenance and Repair
N/A X
6 Illustrated Parts List
N/A X
7 Modification and Changes
N/A X
8 Circuit Diagrams
N/A X
1.2 Purpose of Equipment
The AR6201-(X0X) VHF transceiver enables voice communication in the very
high frequency band between 118.000 MHz and 136.9916 MHz with a
selectable channel spacing of 25 kHz or 8.33 kHz.
The AR6201-(10X) VHF transceiver enables voice communication in the very
high frequency band between 118.000 MHz and 136.9750 MHz with a
selectable channel spacing of 25 kHz only.
1.3 General Notes
The word “frequency”, also used in this document in the sense of
“channel name”, as defined in EUROCAE, ED-23B: chapter 1.3.2.
The word “memory channel” or “channel” used in this document means a
memory place identified by a channel number. On that memory place, a
frequency may be stored for later use.
1.4 Short Description
The AR6201-(X0X) is a single block transceiver ideal to be fitted in all
type of general aviation aircraft and helicopters.
The VHF transceiver is a compact and lightweight single block unit. The
dimensions correspond to the standard instrument diameter of 58 mm (2 ¼
inch). Mounting is by means of four screws (back panel installation).
