AR6201-(X0X)
Page II DV 14300.03/.04 Issue 1 05/1013
Section 2 Installation Page
2.1 Limitations 2-1
2.2 Unpacking the Equipment and
Preparation for Installation 2-1
2.3 Mechanical Installation 2-1
2.4 Electrical Interface 2-2
2.4.1 Connectors and Pin Assignment 2-2
2.4.2 Inputs / Outputs Detailed Description 2-5
2.5 Installation Wiring 2-9
2.5.1 Typical Wiring for Single Seater Glider 2-10
2.5.2 Typical Wiring for Single Seater Glider
(5-pol DIN Jack) 2-11
2.5.3 Typical Wiring for
Twin Seater Motor Glider 2-12
2.5.4 Typical Wiring for
Standard Headsets in use 2-13
2.5.5 Typical Wiring for Aircrafts with
Intercom System (unbalanced) 2-14
2.5.6 Typical Wiring for Aircrafts with
Intercom System (balanced) 2-15
2.5.7 Typical Wiring for Twin Seater Aircrafts,
Tandem (additional R
adio Control Unit) 2-16
2.6 Antenna Installation 2-17
2.7 Location of internal Circuit Breaker 2-17
2.8 Installation Setup 2-18
2.8.1 Entering Installation Setup 2-18
2.8.2 Page Up / Page Down
in the Installation Setup 2-18
2.8.3 Storage of Setup Data 2-18
2.8.4 Terminate Installation Setup 2-18
To Next Page
