Becker Traffic Pro 4720 - Unit Installation and Removal; Installing the Car Radio Unit

142
5HPRYDOLQVWDOODWLRQJXLGH
5HPRYDOLQVWDOODWLRQJXLGH
A universal bracket for DIN installation slots is integrated into this car radio. An installation frame is not required. The unit is
inserted into the installation slot and secured with the slides supplied.
Complete the electrical connections. Then push the unit into the installation slot. Subsequently, push the slides into the apertures
in the front of the unit to the first detent position (Figure A). Now lock the radio by pulling both slides, as shown in Figure B.
Subsequently, remove the slides.
$
%
