8.3 Operation mode lubrication duration
Thelubrication durationof the controlunit PICO-tronicX1 canbe defined„time-dependent“or „speed-dependent“.
8.3.1 Lubrication duration „time-dependent“
Lubrication duration can be set in three set ranges (in minutes and seconds). The monitoring time can be set by means of
thediagnos softwareBAK-DiSys (current versionon BEKAwebsite).
Fig.24:
Setting range for lubrication time:
1to 16min. (16 notchesà 1 minute)
2to 32min. (16 notchesà 2 minutes)
2to 32sek. (16 notchesà 2 seconds)
Timesettingis donewiththe switchin the controlunit window (seefig. 22)
8.3.2 Lubrication duration speed depending
The speed depending control of a central lubrication system counts the number of revolutions of a pump motor. For this
purpose, a sensor is installed in the pump, that sends a signal to the control at each motor revolution. If the signal is
overdue for longer than the set monitoring time (standard 30 sec.), the control unit signals a malfunction (see 12.2 blink
signalof integratedcontrol unit PICO-troniX1).
Pressthe intermediatelubrication button fora reset aftersolving theproblem.
Fig.25:
The set ranges for the number of motor revolutions and for the monitoring time can be changed by means of the BEKA
DiSysSoftware (currentversion on BEKAwebsite).
Set range for number of motor revolutions:
1to 16revolutions (16 notchesà 1 revolution)
10to 160revolutions (16 notchesà 10 revolutions)
170to 320revolutions (16 notchesà 10 revolutions)
Settingof revolutionsis done bymeans of theswitch inthe control unitwindow (see fig.22).
Lubrication time
Cycle duration
Revolutions
Cycle duration
Lubrication /
Pump
© BEKA 201 All rights reserved!6
