Put the pump into operation, e.g. initiate an intermediate lubrication (see 8.1.3 or 9.1.3 function process). The agitator
bladerotates clockwise.
Connect the grease press at the filling nipple and fill up the pump until lubricant comes out of the overfill protection (fig.
56).
Fig.56:
Insertthe overfillprotection and tightenit with atorque of15Nm ±10%.
Fig.57:
Turnthe pumpupside down andfill it untilmax. level.
Fig.58:
Do notoverfill the pump as otherwise lubricant can
leakand causeenvironmental damages.
Overfill protection
K
max. level
Caution!
