Introduction
Before You Get Started
Below is a list of the SpinLite® Full Side Washer equipment you will receive in your shipment and the tools
that are needed to install the equipment.
Tools needed for installation:
Forklift (optional)
Level
Hammer drill with 5/8” bit
50-foot extension cord
Tape measure (25 feet or greater)
Safety glasses
Miscellaneous hand tools
Work gloves
Equipment included: Qty
SpinLite® FSW Driver Side Leg Assembly
1
SpinLite® FSW Passenger Side Leg Assembly
1
SpinLite® FSW Driver Side Arm Assembly
1
SpinLite® FSW Driver Side Arm Assembly
1
SpinLite® FSW Drive Shaft Assembly: 110946
2
SpinLite® FSW Drive Hub Assembly: 111673
2
ShineMitt™ 19” Cleaning Material: 111060
80
ShineMitt™ 22” Cleaning Material: 111053
64
ShineMitt™ 25” Cleaning Material: 111369
32
Motovario Motor/Gearbox STD V: 110935 or 575V: 110967
2
Motor/Gearbox Cover Assembly: 110720
2
SpinLite® FSW LED Light Set: 111674
2
SpinLite® Slip Ring Assembly: 110708
2
SpinLite® FSW Filler Strip: 110746
2
Accessory Box: 108958
1
Accessory Box (108958) includes: Qty
Air Panel Assembly: 102060
1
Kwik Bolts 3 Zinc 5/8” x 6”: 1FSTNR-ST750
12
Clamp Single Ear for 1/2” Hose: 1CLAMP467
4
Keystock 8 x 7 x 100mm: 1STEEL-KY150
2
Collar Lock 2pc Split 1-3/8 x 1/2" wide: 1COLLAR333
2
Arm Pivot Washer: 7202
2
Stainless Steel Flat Washer 9/16”: 1WASHR-FL747
4
Cotter Pin Zinc 1/8 x 1”: 1RETNR129
4
Fasteners HHCS 5/16 – 18 x ¾” ARMOR COAT: 1FSTNR-HH162
4
Lock Washer 5/16” SS: 1WASHR-LC270
4
Note: Uncrate and inspect the shipment for damage, and verify that all pieces are there. If there is any
damaged equipment, file a claim with the trucking company immediately. Receiving party is
responsible for filing a claim with the trucking company. Notify your local distributor or
Belanger, Inc.® immediately if the shipment is determined damaged or incomplete.
